MAGMAWELD 7016 3.2mm Low Hydrogen Stick Electrodes 5KG
$79.00
Product Description
Magmaweld 7016 3.2mm Low Hydrogen Stick Electrodes, 5KG pack, ideal for pipe welding, pressure vessels, and high-toughness steel structures. Offers superior crack resistance with low diffusible hydrogen, X-ray quality welds, and smooth fusion with base metal.
Key Specifications
| Size | 3.2mm diameter, 350mm length |
| Weight | 5kg pack (approx. 167 sticks) |
| Standards | AWS/ASME SFA-5.1, EN ISO 2560-A |
| Mechanical Properties | Yield 490 N/mm2, Tensile 580 N/mm2, 29% Elongation |
| Welding Positions | PA, PB, PC, PD, PE, 4G |
MAGMAWELD 7016 – Low Hydrogen 3.2mm Stick Electrodes – 5KG Pack
Product Description
Experience unmatched welding precision with MAGMAWELD 7016 Low Hydrogen Stick Electrodes. Engineered for industrial-grade performance, these 3.2mm electrodes deliver superior crack resistance and X-ray quality welds, making them ideal for critical applications in pipe welding, pressure vessels, and structural steel. With low diffusible hydrogen content and minimal metal deposition, they ensure pristine root-pass protection against porosity and atmospheric contamination.
Core Features
| Manufacturer | Turkey (MAGMAWELD) |
| Diameter | 3.2mm |
| Length | 350mm |
| Weight | 5kg (167 sticks approx.) |
| Hydrogen Level | Low (H8/H10 classification) |
| Standards | AWS/ASME SFA-5.1, EN ISO 2560-A |
| Approvals | CE, TSE, HAKC |
| Storage | Max 5 re-dries at 350¡ãC for 2 hours |
| Weld Recovery | 115% |
| Welding Positions | PA, PB, PC, PD, PE, 4G |
Key Performance
? Mechanical Strength: Yield strength 490 N/mm2, Tensile strength 580 N/mm2, Elongation 29%
? Toughness: Charpy V-Notch 105J (-20¡ãC), 65J (-40¡ãC)
? Chemical Control: Low C (0.06%), Si (0.35%), Mn (0.85%) for clean, defect-free welds
? Gap Bridging: Superior wetting and fusion for uneven joints
Applications
Perfect for dynamically loaded structures, bridges, shipbuilding, pipelines, boilers, and high-toughness machine components. Ideal for one-sided root-pass welding and buffer layers on high-carbon steels.
Why Choose MAGMAWELD 7016?
? Industrial-Grade Quality: Market-leading brand with proven reliability
? Cost-Efficiency: 115% weld recovery minimizes material waste
? Versatility: Certified for multiple positions and standards (AWS/EN)
? Equivalency: Direct replacement for Bossweld TC16, Cigweld 53163234G0, UNIMIG U63009
FAQ
Q: What is the maximum re-drying cycle?
A: Up to 5 times at 350¡ãC for 2 hours.
Q: Is this suitable for pressure vessel welding?
A: Yes, meets X-ray quality requirements for pressure vessels.
Q: Can it weld high-carbon steel?
A: Ideal for buffer layers on higher carbon steels.
Request a Quote
Ready to elevate your welding projects? Contact us today for bulk pricing, technical support, or custom packaging options. Our team ensures prompt delivery and expert guidance for your industrial needs.
