MAGMAWELD 7016 2.5mm Low Hydrogen Stick Electrodes 5KG
$79.00
Product Description
Magmaweld 7016 is a premium low hydrogen stick electrode ideal for pipe welding of mild steel, offering superior crack resistibility and X-ray quality welds. Suitable for dynamically loaded steel constructions, bridges, shipbuilding, pipelines, and pressure vessels.
Specifications
| Diameter | 2.5mm |
| Length | 350mm |
| Weight | 5kg (243 sticks approx.) |
| Standard | AWS/ASME SFA-5.1 E7016 H8 |
| Welding Positions | PA, PB, PC, PD, PE, PF |
MAGMAWELD 7016 – Low Hydrogen 2.5mm Stick Electrodes – 5KG Pack: Premium Welding Solution for Industrial Excellence
Core Specifications
| Specification | Details |
|---|---|
| Electrode Type | E7016 Low Hydrogen |
| Diameter | 2.5mm |
| Length | 350mm |
| Weight | 5kg (243 sticks approx.) |
| Manufacturing Standard | AWS/ASME SFA-5.1, EN ISO 2560-A |
| Tensile Strength | 580 N/mm2 |
| Yield Strength | 490 N/mm2 |
| Charpy V-Notch (at -20¡ãC) | 105 J |
| Storage Requirement | 350¡ãC drying for 2 hours (max. 5 times) |
| Approvals | CE, TSE, HAKC |
Why Choose MAGMAWELD 7016?
Engineered for critical welding applications, MAGMAWELD 7016 electrodes deliver unmatched performance in pipe welding, pressure vessels, and structural steel. With low diffusible hydrogen content, they minimize crack risk, while superior gap bridging ensures smooth, X-ray quality welds. Trusted by professionals for shipbuilding, bridges, and boilers¡ªwhere toughness and reliability matter most.
Applications & Performance
Ideal for dynamically loaded steel constructions, pipelines, and machinery. The 2.5mm diameter enables precise root-pass welding, while 115% weld metal recovery and minimal spatter reduce material waste. Suitable for all positions (PA, PB, PC, PD, PE, 4G), ensuring versatility across industrial projects.
Quality & Certification
Manufactured in Turkey to international standards (AWS E7016 H8, EN ISO 2560-A E42 4 B12 H10). Backed by CE, TSE, and HAKC certifications, guaranteeing compliance with global quality benchmarks. Each pack includes 243 sticks, optimized for consistent arc stability and clean fusion.
FAQ
Q: What is the maximum drying cycle?
A: The electrodes can be dried up to 5 times at 350¡ãC for 2 hours each cycle.
Q: Is this electrode suitable for high-carbon steel?
A: Yes, it excels at depositing buffer layers on higher carbon steels.
Q: What’s the equivalent to Bossweld products?
A: Equivalent to Bossweld TC16 part# 110400.
